| Model Number: | QS-TL | Type: | Load Cell |
| Place of Origin: | Zhejiang, China | Brand Name: | Santwell |
| Usage: | Truck scale, railway scale, blending scale | Theory: | resistan |
| Output: | Resistance strain | Description: | double ended shear beam |
| Rated Load: | 10t 20t 30t 40t | Sensitivity: | 2.0000±0.002mv/v |
| Total Error: | ±0.02%F.S | Creep(30 minutes): | ±0.02%F.S |
| Recommended Excitation Voltage: | 5V-18V(AC or DC) | Maximum Excitation Voltage: | 24V(AC or DC) |
| Zero Balance: | ±1%F.S | Insulation Impedance: | ≥5000MΩ |
| Safe Overload: | ±150%F.S | UItimate Overload: | ±200%F.S |
Having been through countless days and nights,Ningbo Santwell Import & Export Co., Ltd has successfully developed Brand Hm9b QS 30 ton alloy steel analog weight sensor for trucks double shear beam weightbridge load cell. It is bound to catch people’s eyeballs in various fields. After Brand Hm9b QS 30 ton alloy steel analog weight sensor for trucks double shear beam weightbridge load cell launching into the market, we have gained a lot of support and praise. Most customers think that this kind of products are in line with their expectations in terms of appearance and performance. Ningbo Santwell Import & Export Co., Ltd always adhere to the principle of ‘creating values for customers and bringing benefits to stakeholders’. In the process of development, we highly focus on the quality and ensure no flawless product delivered to customers.
| Model Number: | QS | Type: | Load Cell |
| Place of Origin: | Zhejiang, China | Brand Name: | SantWell |
| Usage: | Truck scale, railway scale, blending scale | Theory: | resistan |
| Output: | Resistance strain | Description: | Double ended shear beam |
| Rated Load: | 30t | Sensitivity: | 2.0000±0.002mV/V |
| Total Error: | ±0.02%F.S | Creep(30minutes): | ±0.02%F.S |
| Recommended Excitation Voltage: | 5V~18V(AC or DC) | Maximum Excitation Voltage: | 24V(AC or DC) |
| Zero Balance: | ±1%F.S | Insulation Impedance: | ≥5000MΩ |
| Safe Overload: | 150%F.S | Utimate Overload: | 200%F.S |
| Model Number: | QS-F | Type: | Load Cell |
| Place of Origin: | Zhejiang, China | Brand Name: | Santwell |
| Usage: | truck scale, PRESSURE SENSOR | Theory: | resistance strain, Resistance Sensor |
| Output: | 1000000d | Description: | double ended beam load cell |
| Sensitivity: | 1000000d | Temperature range,operating: | (-30~+70)℃ |
| Construction: | Alloy Steel | Rated Load: | 10/20/30 T |
| Safe Overload: | 150%F.S | Protection Class: | IP67 & IP68 |
| Output Impedance: | 700±5Ω | Communication Interface: | RS485 |
In the fierce market competition, Ningbo Santwell Import & Export Co., Ltd has grown continuously. We invest in R&D to find better solutions in the Force Sensors & Load Cells industry. We offer buyer Warehouse Measurement 75 Klb 24 V 2Cr14Ni Double Ended shear beam load cell QS-V that they need at prices that fit their pocket. Relying on our excellent products and sensible marketing strategy,Ningbo Santwell Import & Export Co., Ltd hold a firm belief that we will take a large market share in the future and benefit our stakeholders as well.
| Model Number: | QS-S | Type: | Load Cell |
| Place of Origin: | Zhejiang, China | Brand Name: | SantWell |
| Usage: | Truck scale, railway scale, blending scale | Theory: | resistan |
| Output: | Resistance strain | Description: | double ended shear beam |
| Rated Load: | 10t 20t 30t 40t | Sensitivity: | 2.0000±0.002mV/V |
| Total Error: | ±0.02%F.S | Creep(30minutes): | ±0.02%F.S |
| Recommended Excitation Voltage: | 5V~18V(AC or DC) | Maximum Excitation Voltage: | 24V(AC or DC) |
| Zero Balance: | ±1%F.S | Insulation Impedance: | ≥5000MΩ |
| Safe Overload: | 150%F.S | Utimate Overload: | 200%F.S |
| Model Number: | QS-N | Type: | Load Cell |
| Place of Origin: | Zhejiang, China | Brand Name: | SantWell |
| Usage: | Truck scale, railway scale, blending scale | Theory: | resistan |
| Output: | Resistance strain | Description: | double ended shear beam |
| Rated Load: | 10t 20t 30t 40t | Sensitivity: | 2.0000±0.002mV/V |
| Total Error: | ±0.02%F.S | Creep(30minutes): | ±0.02%F.S |
| Recommended Excitation Voltage: | 5V~18V(AC or DC) | Maximum Excitation Voltage: | 24V(AC or DC) |
| Zero Balance: | ±1%F.S | Insulation Impedance: | ≥5000MΩ |
| Safe Overload: | 150%F.S | Utimate Overload: | 200%F.S |
In this era, it is necessary for any enterprise including Ningbo Santwell Import & Export Co., Ltd to improve our R&D strength and develop new products on a regular basis. QS-X 10 20 30 T Specialized Customized Production Alloy Steel Weighbridge 10 Ton Load Cell has made great technological breakthroughs because technicians often hold training and technical exchanges to improve professional skills. Ningbo Santwell Import & Export Co., Ltd have long desired to become one of the most influential enterprises in the industry. At present, we are busy improving our capabilities in product manufacturing, and gathering talents especially technical talents to develop our own core technologies.
| Rated Load |
T
|
10/20/30 |
|
Sensitivity
|
mV/V |
2.0000±0.002
|
| Total Error | %F.S |
±0.02
|
| Creep(30minutes) | %F.S |
±0.02
|
| Recommended Excitation Voltage |
V
|
5 ~18 (AC or DC)
|
| Maximum Excitation Voltage |
V
|
24 (AC or DC)
|
| Zero Balance | %F.S | ±1 |
| Input Impedance | Ω |
775±10
|
| Output Impedance | Ω |
700±5
|
| Insulation Impedance | MΩ | ≥5000 |
| Safe Overload | %F.S | 150 |
| Ultimate Overload | %F.S |
200
|
| Operating Temperature Range | ℃ |
(-30~+70)
|
| Compensated Temperature Range |
℃
|
(-20~+60) |
| Temperature Effect On Load | ℃ |
±0.02%F.S/10
|
| Temperature Effect On Zero | ℃ | ±0.02%F.S/10 |
| Construction | Alloy steel | |
| Protection Class | IP67&IP68 | |
| Citation | GB/T7551-2008/OIML R60 | |
| Mode of Connection |
Input+E:Red Input-E:Black Output+S:Green Output-S:White
|
After years of painstaking research, Ningbo Santwell Import & Export Co., Ltd’s technicians have successfully developed QS-YBC 10T 20T 30T Digital Weighing Sensor Truck Scale Compression 30T Digital Load Cell. The team uses the most advanced production equipment and independent research and development technology to minimize QS-YBC 10T 20T 30T Digital Weighing Sensor Truck Scale Compression 30T Digital Load Cell development cycle and ensure the high quality and strong reliability of the product. Santwell is a solution for all your buying needs. We can offer you the prices that you need and quality that is good for you.
| Model Number: | QS-TL | Type: | Load Cell |
| Place of Origin: | Zhejiang, China | Brand Name: | Santwell |
| Usage: | Truck scale, railway scale, blending scale | Theory: | resistan |
| Output: | Resistance strain | Description: | double ended shear beam |
| Rated Load: | 10t 20t 30t 40t | Sensitivity: | 2.0000±0.002mv/v |
| Total Error: | ±0.02%F.S | Creep(30 minutes): | ±0.02%F.S |
| Recommended Excitation Voltage: | 5V-18V(AC or DC) | Maximum Excitation Voltage: | 24V(AC or DC) |
| Zero Balance: | ±1%F.S | Insulation Impedance: | ≥5000MΩ |
| Safe Overload: | ±150%F.S | UItimate Overload: | ±200%F.S |
Since launched,Load cells, Subminiature force transducers, miniature load cells, Intelligent load cells has been named as one of the best and popular products in our company. Based on scientific strategic decision-making, driven by strong operating capabilities, and driven by technology and R&D capabilities, the products developed and manufactured have clear positioning and goals. In the future, Ningbo Santwell Import & Export Co., Ltd will always adhere to the business philosophy of “people-oriented, innovative development”, based on excellent quality, driven by technological innovation, committed to high-quality products, high-level technology and high-efficiency operations, and promotes the company The economy develops soundly and rapidly.
| Warranty: | 1 year | Customized support: | OEM, ODM, OBM |
| Place of Origin: | Zhejiang, China | Brand Name: | Santwell |
| Model Number: | QSZD | Rated Load: | 10t 20t 30t 40t |
| Sensitivity: | 2.0000±0.002mV/V | Total Error: | ±0.02%F.S |
| Creep(30minutes): | ±0.02%F.S | Recommended Excitation Voltage: | 5V~18V(AC or DC) |
| Maximum Excitation Voltage: | 24V(AC or DC) | Zero Balance: | ±1%F.S |
| Insulation Impedance: | ≥5000MΩ | Safe Overload: | 150%F.S |
| Utimate Overload: | 200%F.S |
Ningbo Santwell Import & Export Co., Ltd is reckoned for manufacturing and supplying QS-R IP67 Water Proof 5 -10 Ton Truck Railway Blending Weight Sensor Half Bridge Load Cell For Digital Scale that is manufactured using supreme quality materials. Based on scientific strategic decision-making, driven by strong operating capabilities, and driven by technology and R&D capabilities, the products developed and manufactured have clear positioning and goals. Get in touch with us – call, fill in our online form or connect via live chat, we are always happy to help.
| Model Number: | QS-R | Type: | Load Cell |
| Place of Origin: | Zhejiang, China | Brand Name: | Santwell |
| Usage: | Truck scale, railway scale, blending scale | Theory: | resistan |
| Output: | Resistance strain | Description: | Double Ended Shear Beam |
| Rated Load: | 10T | Sensitivity: | 2.0000±0.002mv/v |
| Total Error: | ±0.03%F.S | Creep(30 minutes): | ±0.02%F.S |
| Recommended Excitation Voltage: | 5V~18V(AC or DC) | Maximum Excitation Voltage: | 24V(AC or DC) |
| Zero Balance: | ±1%F.S | Insulation Impedance: | ≥5000MΩ |
| Safe Overload: | 150%F.S | UItimate Overload: | 200%F.S |
Ningbo Santwell Import & Export Co., Ltd is capable of providing a quality range of Shear beam load cell 2 ton Pressure Plate weight sensor Tank Weigh 6 Ton load cell QS-KL. Technological innovation is the fundamental reason for Ningbo Santwell Import & Export Co., Ltd to achieve sustainable development. Ningbo Santwell Import & Export Co., Ltd always adhere to the principle of ‘creating values for customers and bringing benefits to stakeholders’. In the process of development, we highly focus on the quality and ensure no flawless product delivered to customers.
| Model Number: | QS-KL | Place of Origin: | Zhejiang, China |
| Brand Name: | santwell | Usage: | PRESSURE SENSOR |
| Theory: | Resistance Sensor | Output: | Analog SENSOR |
| Rated Load: | 3t~6t | Sensitivity: | 2.0000±0.002mv/v |
| Total Error: | ±0.02%F.S | Creep(30 minutes): | ±0.02%F.S |
| Recommended Excitation Voltage: | 5V~18V(AC or DC) | Maximum Excitation Voltage: | 24V(AC or DC) |
| Zero Balance: | ±1%F.S | Insulation Impedance: | ≥5000MΩ |
| Safe Overload: | 150%F.S | UItimate Overload: | 200%F.S |
State-of-the-art technologies introduced and upgraded for the more efficient and stable manufacturing of the product. It functions perfectly in the application scenario(s) of Force Sensors & Load Cells. We can provide you with the highest quality products within your budget. Santwell has been dedicated to the design, R&D, manufacturing, and updates of Load cells, Subminiature force transducers, miniature load cells, Intelligent load cells. We fully hope that we can satisfy customers from different fields, countries, and regions by offering them high-quality products and professional service. If you have any questions or problems, please contact us at any time through the contact information listed on our website.
| Model Number: | QS-YBF | Type: | Load Cell |
| Place of Origin: | Zhejiang, China | Brand Name: | Santwell |
| Usage: | truck scale | Theory: | resistan |
| Output: | Resistance strain | Description: | Double ended shear beam load cell |
| Rated Load: | 10/20/30 T | Sensitivity: | 2.0000±0.002mv/v |
| Total Error: | ±0.02%F.S | Creep(30 minutes): | ±0.02%F.S |
| Recommended Excitation Voltage: | 5V-18V(AC or DC) | Maximum Excitation Voltage: | 24V(AC or DC) |
| Zero Balance: | ±1%F.S | Insulation Impedance: | ≥5000MΩ |
| Safe Overload: | ±150%F.S | UItimate Overload: | ±200%F.S |
Ningbo Santwell Import & Export Co., Ltd has a number of elite teams in management, design, R&D, and production. Our product can be tailored to suit you perfectly. Under the leadership of our company’s board of directors, Ningbo Santwell Import & Export Co., Ltd have constantly upgraded our technologies and introduced high-end machines to continuously drive the market trend and improve product quality so as to satisfy every customer. Our aim is to become one of the most trustworthy enterprises in the market.
| Model Number: | QS-KX | Type: | Load Cell |
| Place of Origin: | Zhejiang, China | Brand Name: | santwell |
| Usage: | truck scale | Theory: | resistan |
| Output: | Resistance strain | Description: | Double ended shear beam load cell |
| Rated Load: | 10t-30t | Sensitivity: | 2.0000±0.002mv/v |
| Total Error: | ±0.02%F.S | Creep(30 minutes): | ±0.02%F.S |
| Recommended Excitation Voltage: | 5V~18V(AC or DC) | Maximum Excitation Voltage: | 24V(AC or DC) |
| Zero Balance: | ±1%F.S | Insulation Impedance: | ≥5000MΩ |
| Safe Overload: | 150%F.S | UItimate Overload: | 200%F.S |
| Model Number: | QS-J | Type: | Load Cell |
| Place of Origin: | Zhejiang, China | Brand Name: | santwell |
| Usage: | truck scale | Theory: | resistan |
| Output: | Resistance strain | Description: | Double ended shear beam load cell |
| Rated Load: | 10t-30t | Sensitivity: | 2.0000±0.002mv/v |
| Total Error: | ±0.02%F.S | Creep(30 minutes): | ±0.02%F.S |
| Recommended Excitation Voltage: | 5V~18V(AC or DC) | Maximum Excitation Voltage: | 24V(AC or DC) |
| Zero Balance: | ±1%F.S | Insulation Impedance: | ≥5000MΩ |
| Safe Overload: | 150%F.S | UItimate Overload: | 200%F.S |
