Santwell / QS-F / QS-KL 탱크용 계량 로드셀


State-of-the-art technologies introduced and upgraded for the more efficient and stable manufacturing of the product. It functions perfectly in the application scenario(s) of Force Sensors & Load Cells. High-quality Tank Scales load cell 20 ton Alloy Steel Classic Design Dry Mortar weight sensor load cell QS-KL rely on strong research and development capabilities and a good brand image. Ningbo Santwell Import & Export Co., Ltd adhere to the corporate spirit of ‘pragmatism & innovation’ and aim to create benefits for our stakeholders. Driven by the fierce competition in the market, Ningbo Santwell Import & Export Co., Ltd hold a firm belief that we must focus on R&D and develop new technologies to adapt to the market trends.

Model Number: QS-KL Place of Origin: Zhejiang, China
Brand Name: Santwell Usage: PRESSURE SENSOR
Theory: Resistance Sensor Output: Analog SENSOR
Rated Load: 3t~6t Sensitivity: 2.0000±0.002mv/v
Total Error: ±0.02%F.S Creep(30 minutes): ±0.02%F.S
Recommended Excitation Voltage: 5V~18V(AC or DC) Maximum Excitation Voltage: 24V(AC or DC)
Zero Balance: ±1%F.S Insulation Impedance: ≥5000MΩ
Safe Overload: 150%F.S UItimate Overload: 200%F.S




Share it:

Tank Scales load cell 20 ton Alloy Steel Classic Design Dry Mortar weight sensor load cell QS-KL has been tested to conform to international standards. Developed by our creative R&D experts and manufactured by our skilled workers, it has excellent features. With those superiorities, Load cells, Subminiature force transducers, miniature load cells, Intelligent load cells will surely stand out and provide customers with benefits in the market.

Specification :  10T, 20T, 30T

shipping: Support Sea freight · Land freight<

Customization: Customized logo (Min. Order: 100 Pieces),Customized packaging (Min. Order: 100 Pieces),Graphic customization (Min. Order: 100 Pieces)

Technical Parameter

Rated Load 3~6t
Sensitivity 2.0000±0.002mV/V
Total Error ±0.02%F.S
Creep(30minutes) ±0.02%F.S
Recommended Excitation Voltage 5V~18V(AC or DC)
Maximum Excitation Voltage 24V(AC or DC)
Zero Balance ±1%F.S
Input Impedance 775±10Ω
Output Impedance 700±5Ω
Insulation Impedance ≥5000MΩ
Safe Overload 150%F.S
Ultimate Overload 200%F.S
Operating Temperature Range (-30~+70)℃
Compensated Temperature Range (-20~+60)℃
Temperature Effect On Load ±0.05%F.S/10℃
Temperature Effect On Zero ±0.02%F.S/10℃
Construction Aluminum
Protection Class IP67&IP68
Citation GB/T7551-2008/OIML R60
Mode of Connection Input+E:Red Input-E:Black Output+S:Green Output-S:White
