Our Spoke Style load cell force testing, 250t is developed by our creative designers, experienced technicians, and well-educated R&D experts. It is made to be of an attractive look and reasonable structure. Moreover, made of high-quality raw materials, Load cells, Subminiature force transducers, miniature load cells, Intelligent load cells has so many advantages.
Shipping: Support Sea freight · Land freight
Customization: Customized packaging；Graphic customization
|
Sensitivity
|
mV/V
|
2.0000±0.002
|
|
Total Error
|
%F.S
|
±0.1
|
|
Creep(30minutes)
|
%F.S
|
±0.02
|
|
Recommended Excitation Voltage
|
V
|
5 ~18 (AC or DC)
|
|
Maximum Excitation Voltage
|
V
|
24 (AC or DC)
|
|
Zero Balance
|
%F.S
|
±1
|
|
Input Impedance
|
Ω
|
775±10
|
|
Output Impedance
|
Ω
|
700±5
|
|
Insulation Impedance
|
MΩ
|
≥5000
|
|
Safe Overload
|
%F.S
|
150
|
|
Ultimate Overload
|
%F.S
|
200
|
|
Operating Temperature Range
|
℃
|
(-30~+70)
|
|
Compensated Temperature Range
|
℃
|
(-20~+60)
|
|
Temperature Effect On Load
|
℃
|
±0.02%F.S/10
|
|
Temperature Effect On Zero
|
℃
|
±0.02%F.S/10
|
|
Construction
|
Alloy steel
|
|
|
Protection Class
|
IP67&IP68
|
|
|
Citation
|
GB/T7551-2008/OIML R60
|
|
|
Mode of Connection
|
Input+E:Red
Input-E:Black
Output+S:Green
Output-S:White
|
