Product Introduction:
◎Material: alloy steel;
◎Measuring range fxyz:50/100/200kn;
◎Comprehensive accuracy: 0.5% FS;
◎Output signal: 1.0mV/V;
Dimension:
Technical Parameter：
Fx Fy Fz Each 30N Mx My Mz Each 1.5Nm 0.1%F.S. IP64 Hard Aluminum Alloy Six Axis Force Sensor FARS36A is a model from FARS36 which is in six-axis force sensor category. FARS36A can measure 6-axis force Fx,Fy and Fz are 30N, Mx,My and Mz are 1.5Nm, its Diameter is 36mm and Height is 20mm, its weight is 0.04kg.
Fx Fy 400N Fz 500N Mx My Mz 12Nm Hard Aluminum Alloy Six Axis Force Sensor FARS82C is a model of Six Axis Force Sensor, it belongs to FARS82 in our brand FIBOS FARS-Series, Six Axis Force Sensor FARS82C can measure multi-axis force Fx,Fy are both 400N, Fz is 500N, Mx,My,Mz are all the same 12Nm, its Diameter is 82mm and Height is 33.5mm, its weight is 0.32kg.
Fx Fy Fz 150N Mx My Mz 6Nm 0.1%F.S. Hard Aluminum Alloy Six Axis Force Sensor FARS62C is a model of Six Axis Force Sensor, it belongs to FARS62 in our brand FIBOS FARS-Series, FARS62C can measure multi-axis load Fx,Fy,Fz are 150N, Mx,My,Mz are 6Nm, its weight is 0.16kg, its Protection Level is IP64.
Fx Fy Fz 200N Mx My Mz 8Nm Hard Aluminum Alloy Six Axis Force Sensor FARS82B is a model from FARS82 which belongs to our brand FIBOS FARS-Series, FARS82B can be used to measure six-axis force Fx,Fy,Fz all are same 200N, Mx,My,Mz are same 8Nm, its Diameter is 82mm and Height is 31.5mm, its weight is 0.28kg.
Fx Fy Fz 30N Mx My Mz 1.5Nm Hard Aluminum Alloy Six Axis Force Sensor FARS75E is a model of our brand FIBOS FARS-Series, it belongs to FARS75 which is its mother model in six axis force sensor, FARS75E can be used to measure six axis force Fx,Fy and Fz are 30N, Mx,My,Mz are 1.5Nm, its Diameter is 75mm and Height is 31.5mm.
Fx Fy Fz Each 150N Mx My Mz Each 5Nm 0.1%F.S. IP64 Hard Aluminum Alloy Six Axis Force Sensor FARS46B is a model of our brand FIBOS FARS-Series, it belongs to FARS46. FARS46B can be used to measure multi-axis force Fx,Fy and Fz are the same 150N, Mx,My and Mz are all 5Nm, its Diameter is 46mm and Height is 19.4mm, its weight is 0.05kg.
Fx Fy Fz 50N Mx My Mz 2Nm 0.1%F.S. Hard Aluminum Alloy Six Axis Force Sensor FARS62A is a model of Six Axis Force Sensor, it belongs to FARS62 in our brand FIBOS FARS-Series, it can be got to measure multiple axis load Fx,Fy,Fz are 50N, Mx,My,Mz are 2Nm, its weight is 0.12kg, its shape makes it also look like FARS62.
Fx Fy 200N Fz 400N Mx My Mz 18Nm Hard Aluminum Alloy Six Axis Force Sensor FARS94B belongs to FARS94 which is in Six Axis Force Sensor category of our brand FIBOS FARS-Series, FARS94B could be used to measure 6-axis force that Fx,Fy are both 200N, its Fz is 400N, and Mx,My,Mz are all 18N.m, its Height is 26mm.
Fx Fy 100N Fz 200N Mx My Mz 10Nm 0.1%F.S. Hard Aluminum Alloy Six Axis Force Sensor FARS94A is a model of Six Axis Force Sensor, it belongs to FARS94 in our brand FIBOS FARS-Series, it can be used to measure multi-axis load Fx,Fy are 100N, Fz is 200N, Mx,My,Mz all are 10Nm, its Diameter is 94mm and Height is 26mm, its Material is Hard aluminum alloy.
Fx Fy Fz 50N Mx My Mz 2Nm 0.1%F.S. Hard Aluminum Alloy Six Axis Force Sensor FARS82A is a model of our FIBOS FARS-Series, it belongs to FARS82 which is its mother model, FARS82A can be used to measure 6-axis force Fx,Fy,Fz are same 50N, and Mx,My,Mz are same 2Nm, its weight is 0.26kg, it has very similar shape with FARS82.
Fx Fy 500N Fz 700N Mx My Mz 18Nm Hard Aluminum Alloy Six Axis Force Sensor FARS82D is a model from FARS82 which belongs to our brand FIBOS FARS-Series, FARS82D can be used to measure six axis force Fx,Fy are both 500N, Fz is 700N, and Mx,My,Mz are all 18Nm, its weight is 0.36kg, it’s heavier than FARS82.
0.1%F.S. IP64 Hard Aluminum Alloy Six Axis Force Sensors FARS75A is a model of our brand FIBOS FARS-Series, it belongs to 6-axis force sensor FARS75. FARS75A can be used to measure six-axis force Fx,Fy and Fz are 50N, Mx,My and Mz are all 2Nm, its Diameter is 75mm and Height is 31.5mm, its weight is 0.26kg.
