Product introduction:
◎Measuring range: 2Nm… 2KNm;
◎Accuracy:±0.1% FS, 0.25% FS, 0.5% FS;
◎Resistance strain is an integrated product composed of sensitive elements and integrated circuits
◎High precision, stable and reliable performance;
◎Output forward and reverse torque signals, with both ends connected by keys;
◎The maximum speed shall not exceed 8000 rpm;
◎It is widely used in pull pressure testing instruments such as plug-in force tester, rivet machine, welding machine, cold and hot press film pasting machine, keyboard button hand sensitivity tester, as well as automation equipment and testing field;
Dimension:
| Cap.(Nm) |
A |
ql |
B |
C |
D |
E |
F |
K |
N |
M |
H |
Max. Speed |
| 2-100 |
108 |
18 |
44 |
38 |
58 |
30 |
22 |
19 |
6 |
3-M3 |
6 |
1800rpm |
| 150-500 |
143 |
28 |
56 |
53 |
73.5 |
40 |
30 |
27 |
6 |
3-M3 |
8 |
1800rpm |
| 1-2K |
221 |
50 |
97 |
90 |
125 |
60 |
50 |
45 |
33 |
4-M4 |
16 |
300rpm |
Technical Parameter：
| Cap. |
2/5/10/20/50/100/200/500Nm,1K-2KNm |
| Response frequency |
100μS |
Input resistance |
750±10Ω |
| Material |
Alloy stainless |
Output resistance |
750±5Ω |
| Output sensitivity |
1-1.5mV/V |
Insulation resistance |
≥5000MΩ/100VDC |
| Zero output |
±1%FS |
Service voltage |
5-10V |
| Nonlinear |
±0.1,±0.3%FS |
Maximum voltage |
15V |
| Lagging |
≤±0.05%FS |
Temp. compensation range |
-10~+60℃ |
| Repeatability |
≤±0.05%FS |
Working temperature |
-20~+80℃ |
| Creep (30 Minutes) |
≤±0.03%FS |
Safe Overload |
150% |
| Sensitivity temp. drift |
0.03%FS/10℃ |
Ultimate overload |
200% |
| Zero temp.drift |
0.03%FS/10℃ |
Cable size |
φ5.2×3m |
| Product name |
LCT017 Rotating Torque Meters Dynamic Torque Sensing Dynamic Torque Meters |
| Brand |
SAINTBOND |
| Market |
All over the world |
| Features |
High precision and stable performance |
| Advantage |
0EM/ODM |
| Sample Lead Time |
5~ 40Days |
| Sample price |
The price is different according to product capacity |
| Custom Design |
Welcome |
| Form of sale |
Factory supply |
