This product is made of high-quality alloy steel, offering excellent stability and resistance to signal interference. It can be installed in confined spaces and customized to specific requirements, making it widely used for pressure and force measurement in various industrial applications.

This product is made of high-quality alloy steel, offering excellent stability and resistance to signal interference. It can be installed in confined spaces and customized to specific requirements, making it widely used for pressure and force measurement in various industrial applications.

50-70t Spoke Type Load Cell FA120C is a model of our brand FIBOS FA1-Series, it belongs to FA120 which is in Spoke Type Load Cell category, FA120C can be used to measure load 50t and 70t capacity, its Zero Balance range is ±1%F.S., its Creep(30min),Non-linearity,Hysteresis and Repeatability all ≤0.05%F.S..

The LCC460 load cell features a washer-type force sensor, pressure sensor, and cylindrical structure, with capacities ranging from 5 tons to 300 tons. Customization is available according to customer requirements. Made of alloy steel with a nickel-plated surface, it boasts high overall accuracy and excellent long-term stability. Its compact design and easy installation make it ideal for force control and measurement.

10-200kN Stainless Steel Ring Force Sensor FA117 is a model of our brand FIBOS FA1-Series, it belongs to Ring Force Sensor category. FA117 can be used to measure force ranges from 10kN, 20kN, 30kN, 50kN, 100kN up to 200kN capacity, its Zero Balance is ±5%mV/V, its Creep(30min),Non-linearity and Repeatability all ≤0.1%F.S., its Hysteresis ≤0.2%F.S..

Weighing Capacity Range 0-250ton High Precision Spoke load cell has these functions:

1. Low height, small deformation and small overall dimension

2. Stainless steel material, high temperature can be customized

3. Protection grade IP674. Explosion-proof grade: Ex ia IIC T4 Ga; Ex iaD 20 T1355.

50,100,150,200t or customized Spoke Type Load Cell FA120F is a model of our brand FIBOS FA1-Series, it belongs to FA120 which belongs to Spoke Type Load Cell category. FA120F can be used to measure load 50t,100t,150t and 200t or customized capacity, its Creep(30min),Non-linearity and Hysteresis all ≤0.08%F.S. or can be customized, and its Repeatability ≤0.09%F.S. or also can be customized.

10-2000kg Stainless Steel Ring Force Sensor FA115 is a model of our brand FIBOS FA1-Series, Ring Force Sensor FA115 can be used to measure force 10kg,20kg,50kg,100kg,200kg,300kg, 500kg,1000kg and 2000kg capacity, its Creep(30min) ≤0.1%F.S., its Hysteresis and Repeatability both ≤0.2%F.S., and its Non-linearity ≤0.3%F.S..

The LCD804 low-profile disc load cell, 2-ton force sensor, and 3-ton disc force sensor are constructed of aluminum steel with an IP65 protection rating. Their weighing capacities range from 0.2 to 3 tons.

ChatGPT의 말:

0.1-30t ≤0.05%F.S. Alloy Steel Miniature Industrial Automation Applied Spoke Type Load Cell FA120B is a model of our brand FIBOS FA1-Series, Spoke Type Load Cell FA120B can be used to measure load 0.1t,0.2t,1t,2t,3t,5t,10t,15t,20t and 30t capacity, its Non-linearity ≤0.05%F.S. and its Repeatability ≤0.03%F.S..

1,2,3,5,10,20kN Ring Force Sensor FA1028 is a special model of our brand FIBOS FA1-Series, it also belongs to Ring Force Sensor category. FA1028 can be used to measure force 1kN,2kN,3kN,5kN,10kN and 20kN or customized capacity, its Creep(30min),Non-linearity and Repeatability all ≤0.1%F.S. or can be customized, its Hysteresis ≤0.2%F.S. or can also be customized.
