SAINTBOND / LC104C Load Limiting Device Wire Rope Clamp-on Tension Load Cell for Clamp on Rope

Add to Wishlist
Share it:

LC104C Load Limiting Device Wire Rope Clamp-on Tension Load Cell for Clamp on Rope

Product Description

LC104C-5

Dimension: in mm

LC104C

Products specification:

This mechanical load cell has been designed to provide a trip point for lifting systems which have a dead end wire rope. The trip point provides a signal that the user may employ depending on his requirements, e.g.

◎For load limiting in lifting systems

◎To limit the speed as a function of the load on traversing

◎To limit the effort applied for pulling

This universal load cell is recommended for its simplicity and quick lifting capability.



Technical Parameter:

Capacity: 30/40t Insulation Resistance: ≥5000MΩ
Wire Rope Size: 6~40mm Operating Temp. Range: -30~+70℃
Sensitivity: 1.0~2.0mV/V Maximum Safe Over Load: 120%F.S
Combined Error: ±0.1% F.S Ultimate Over Load: 300%F.S
Creep Error(30min): ±0.02% F.S Recommend Excitation Vol.: 10~12V DC
Zero Balance: ±1% F.S Max. Excitation Voltage: 15V DC
Temp. Effect On Zero: ≤±0.03％F.S/10℃ Sealing Class: IP67
Temp. Effect On Span: ≤±0.03％F.S/10℃ Element Material: Alloy Steel, Stainless Steel
Input Resistance: 380±30Ω Cable: Length=1m
Output Resistance: 350±2Ω Citation: GB/T7551-2008/ OIML R60



Technical Parameter：

Wireless Frequency: 430~485MHz
Wireless Distance: Min:800m(In Open Area)
A/D Conversion Rate: ≥50times/seconds
Operating Temp. Range: -20～+80℃
Operating Humidity: ≤85%RH under 20℃
Battery Life: ≥50 hours
Non-Linearity: 0.01%F.S
Stable Time: ≤5 Seconds
Citation: GB/T7551-2008/ OIML R60



Product name LC104C Load Limiting Device Wire Rope Clamp-on Tension Load Cell for Clamp on Rope
Brand SAINTBOND
Market All over the world
Features High precision and stable performance
Advantage 0EM/ODM
Sample Lead Time 5~ 40Days
Sample price The price is different according to product capacity
Custom Design Welcome
Form of sale Factory supply
