LC1002C Low Profile Compression Load Cells 10ton Weighing Load Cell 4/10/20/30/40/50Klb

Product Description

LC1002C_01

Technical Parameter:





Rated Load: 4/10/20/30/40/50Klb
Sensitivity: (1.0±0.1%) mV/V Operating Temp. Range: -30~+70℃
Combined Error: ±0.02% F.S Max. Safe Over Load: 150%F.S
Creep Error(30min): ±0.02% F.S Ultimate Over Load: 300%F.S
Zero Balance: ±1% F.S Recommend Excitation Vol.: 10~12V DC
Tco: ±0.02% F.S/10℃ Max. Excitation Voltage: 15V DC
Tc Span: ±0.02% F.S/10℃ Sealing Class: IP67/IP68
Input Resistance: 380±30Ω Element Material: Alloy Steel, Stainless Steel
Output Resistance: 350±2Ω Cable: Length=L:12m
Insulation Resistance: ≥5000MΩ Citation: GB/T7551-2008/ OIML R60


LC1002C_02

Product name LC1002C Low Profile Compression Load Cells 10ton Weighing Load Cell 4/10/20/30/40/50Klb
Brand SAINTBOND
Market All over the world
Features High precision and stable performance
Advantage 0EM/ODM
Sample Lead Time 5~ 40Days
Sample price The price is different according to product capacity
Custom Design Welcome
Form of sale Factory supply
