LP7110F Shear Beam Load Cell
Rated Capacity: 1/2/2.5/3/5t
Accuracy Class: C3
Rated Output: 2.0±0.002 mV/V, 3.0±0.003mV/V
Total error: ±0.02%F.S
Creep(30min): ±0.02%F.S
Input Resistance: 385±10Ω
Output Resistance: 351±2Ω
Operating Temperature: -10~+40℃
Safe Overload: 150%F.S
Destructive Load: 200%F.S
Excitation Recommend: 4~12VDC Max:15VDC
Cable Length: 2.5~5m 4 wires with shield
Exc+(red) Exc-(black) Sig+(green) Sig-(white)
Construction: Alloy Steel,IP67
Application for: Hopper scale,blending scale, weighing module etc.
