1000 Series Small-Range Spoke Type (Fatigue Grade)
Technical parameters
Dimensions
The KWT1C25 is a tensile pressure sensor in a compact design. The special structural design makes the height of the sensor only 36 mm, which is an excellent choice for force measurement in a small space, and is very suitable for applications with a large measuring range and a small use space.
The S beam load cell provides good restraint to possible movement of the automation and in many cases. The small size gives excellent performance for high capacity loading. The output is rationalized to facilitate multiple-cell application. ZMSA is contructed of stainless steel and is potted to IP67 providing excellent protection against moisture and humidity.
Features:
Capacity 1kg-100kg
Both tension and compression
Rational outputs
Stainless steel
Optional features:
Hermetically sealed available
Various industrial weighing systems such as testing machines, truck scales, hopper scales, etc.
Various industrial weighing systems such as testing machines, truck scales, hopper scales, etc.
This product enables dynamic measurement with a fast response speed and maintains static calibration stability over time. It has minimal sensitivity error for both tension and compression forces, making it ideal for applications requiring precise force measurement.
ZMMA-SS is small size force sensor for compression and tension. Widely used on automation machine and small force test purpose.
Features:
Capacity 5N,10N,20N,50N,100N,200N
Compact size
Stainless steel construction
Both compression and tension
Optional features:
0-5V, 4-20mA output signal
The ZMHB double-ended mounting provides good restraint to possible movement of the tanks and, in many cases, eliminates the needs for check rods. The shear beam design gives excellent performance for high capacity loading. The ZMHB is constructed of alloy steel and is potted to IP67 providing excellentt protection against moisture and humidity.
Features:
Capacity 1Klb-50Klb
High accuracy
High stability
Nickel plated alloy steel
Optional features:
Stainless steel construction
The ZMQS is double ended shear beam load cell, capacity from 1t up to 30t. The load cell has high accuracy and high stability, widely used in elevator industry.
Features:
Capacity 1t-30t
High accuracy
High stability
Nickel plated alloy steel
Optional features:
Stainless steel construction
Various industrial weighing systems such as testing machines, truck scales, hopper scales, etc.
ZMMA-CS is miniature type force sensor for both of compression and tension usage.
Features:
Capacity 2N,3N,5N,10N,20N,30N,50N
Compact size
Stainless steel construction
Both compression and tension
Optional features:
0-5V, 4-20mA output signal
Various industrial weighing systems such as testing machines, truck scales, hopper scales, etc.
The ZM2DW force sensor F, M utilizes independent wheatstone full bridge for each axis which provides mV/V output proportional to the applied force and requires no mathematical manipulation. Typical applications for this type of transducer are for example force exertion control in robotics, automotive crash testing, industrial test benches, grinding force control, actuator operating force measurement,etc.
Features:
F from 20N to 2000N
M from 1N.m to 50N.m
Low crosstalk
Compact size
Optional features:
0-5V output signal
