ZMMA-CS is miniature type force sensor for both of compression and tension usage.

Features:

Both compression and tension

The ZMME-S is a series of miniature force transducers designed for applications in general test and measurement as well as machine monitoring and control. The threaded construction enables the ZMME-S to be easily assembled into equipment under test where both tension and compression forces require monitoring.

Stainless steel construction

The ZMWMC is constructed from stainless steel and protected from moisture with an epoxy bonded cover. ZMWMC is configured for both of compression and tension force measurement. Full-bridge, bonded foil strain gauge technology provides excellent long-term stability and ensures high performance even in applications requiring in excess of 1 million load cycles.

Stainless steel

• Measuring range: ±5-±200mm
• Range: 30-400mm
• Beam diameter: about ∮50-500um
• Linearity: ±0.1%FS※1
• Temperature characteristics: 0.03%FS/℃
• Protection class: IP67
• Product Name: Miniature Laser Ranging Sensor HG-C Series
• customizable

Model 53 load cells are bonded foil strain gage transducers designed for cost efficient production and testing applications (i.e. press calibration). Engineered compression force measurements up to 50K lb., this model achieves a maximum non-linearity of 0.5 % full scale. Precision gaging techniques and a stainless steel construction provides excellent long-term stability and reliability under severe operating conditions. The Model 53 compression-only load cell has an integral load button machined as part of the load cell. The Model 53 must be mounted on a smooth flat surface for proper operation. Three tapped holes are provided for mounting.

The ZMSGA provides good restraint to possible movement of the automation and in many cases. The load cell has overload preventer which can protect sensor under extrem overloding situtation. The small size gives excellent performance for high capacity loading. The output is rationalized to facilitate multiple-cell application. ZMSGA is contructed of stainless steel and is potted to IP67 providing excellent protection against moisture and humidity.

Stainless steel

Model LFH-7I subminiature load cell is a low profile force transducer for applications with minimal space and high capacity requirements. This transducer utilizes foil strain gages to measure compression loads of up to 10,000 lb and achieves accuracy of ±0.7 % full scale. The top of the load cell is the area where the force is applied and the base ring of the load cell must be placed on a hard, machine-ground flat surface to obtain optimum accuracy.

The ZMPA is a series of low capacity, aluminium single-point load cells intended for a wide range of industrial applications. The ZMPA convert proportionally the mechanical input variable force into the electrical variable voltage. The load cells are ideal for use in platform scalem weighfeeders and bin weighers. The compact design facilitates planning into any given construction.

ZMMA-YS is mini type force transducer, widely used on UTM and compression&tension force applications.

Features:

Both compression and tension

The ZMMC3 is through-hole force sensor which is available in a wide range of standard capacities from 50N through to 1000N. Zhimin offers custom solutions which help you design your unique load cell application. For wahser type load cell, we need to know your required diameter and through hole size. In order to reduce your cost, zhimin can produce sensors according to your current products. Our aim is to provide best solutions for your precious clients.

Stainless steel construction

Widely used in auto press assembly, automated assembly, 3C product testing,
New energy product assembly, medical testing, robotics;High dynamic response frequency.

Material: stainless steel, Customizable high temperature performance
Size: Small size, Low height
