100,200,1000,2000,3000N.m Or Customized Static Torque Sensor Force Torque Sensor FA625B belongs to FA625 which belongs to Static Torque Sensor of Force Torque Sensor category, FA625B can be used to measure Static Torque force 100N.m,200N.m,1000N.m,2000N.m and 3000N.m or customized capacity, its Cable size is ⌀6x4500mm or can be customized.
0.1-500N.m IP66 dynamic torque sensor FA604 is a model of our brand FIBOS FA6-Series, it belongs to torque sensor, FA604 can be used to measure torque force 0.1N.m, 0.2N.m, 0.3N.m, 0.5N.m, 1N.m, 2N.m, 3N.m, 5N.m, 10N.m, 20N.m, 30N.m, 50N.m, 100N.m, 200N.m, 300N.m and 500N.m capacity, its Creep(30min) and Repeatability both same ≤0.1%F.S., its Non-linearity and Hysteresis both ≤0.2%F.S..
Suitable for dynamic, bearing, torque wrench and other testers
A dynamic torque sensor is a precision measuring instrument capable of measuring the output torque and power of rotating power equipment It is widely used in torque and power testing of rotating power equipment such as electric motors, engines, and internal combustion engines, as well as torque and power testing of mechanical components such as fans, water pumps, gearboxes, and torque wrenches.
The ZMZNJ is dual range shaft torque sensor. The torque sensor measures shaft-shaft type connection, measuring torsion by strain gages. There are both analog and digital output signals available for evaluation. The stainless steel construction is optional.
Features:
Capacity 100Nm-5000Nm
High precision
Easy and fast installation
Nickel plated alloy steel
Optional features:
Stainless steel construction
5-500N.M IP66 Dynamic Torque Sensor Force Torque Sensor FA603 is a model of our brand FIBOS FA6-Series, Dynamic Torque Sensor Force Torque Sensor FA603 can be used to measure dynamic torque force ranges from 5N.m,10N.m,20N.m,50N.m,100N.m,200N.m and 500N.m capacity, its Rated output range is 1.0~1.5mV/V, its Zero Balance range is ±0.01mV/V.
This sensor is suitable for most domestic and foreign cooperative robots. It is an embedded high-precision six-axis force sensor that our company hot sells. It uses silicon strain gauge, based on the principle of strain electrical measurement to convert the load into voltage signal, combined with six axis joint calibration technology to make the product achieve higher accuracy and precision. It is widely used in 3C testing, medical testing, drag teaching, automobile testing, and other fields.
1、Static torque sensor is a kind of sensor used to measure the torque of a stationary or slowly rotating object.
2、The flange mounted sensor is connected with a load transfer device, which can output voltage or current signals.
3、It is used for static discontinuous rotation, non-standard customization, anti-interference signal stability, and is widely used in static torque testing systems such as testing machines, torque wrenches, steering gears, electric actuators, valves, transmissions, and hydraulic pressure.
4、Small size, light weight and convenient installation and use.
5、 High detection accuracy, good stability and strong anti-interference ability.
Static torque sensor is an instrument that converts the strain generated by torsional torque into an electrical signal with a linear relationship according to the principle of resistance strain, the product has mature manufacturing technology, complete variety, wide range, high precision, stable and reliable performance. It is widely used in testing machines, static torque detection and other test systems.
The ZHKY2050A is a series of non-contact type torque sensors ideal for testing and measurement of industrial rotating machines. Designed to be small and rugged it can easily be installed in a variety of industrial applications. The sensor can output torque and speed for measuring power exerted by the attached rotating machine.
