Models
FA606
Features
Sensitivity：1.5±10%mV/V
Accuracy：≤0.1%F.S.
Material：Aluminium Alloy
Dimensions
Specifications
| Item | Unit | Specification |
|---|---|---|
| Capacity | N·m | 0.1, 0.2, 0.5, 1, 2, 3, 5, 10 |
| Sensitivity | mV/V | 1.5 ± 10% |
| Zero Balance | mV/V | ±2% |
| Creep | %F.S. | ≤ 0.05 |
| Non-linearity | %F.S. | ≤ 0.1 |
| Hysteresis | %F.S. | ≤ 0.05 |
| Repeatability | %F.S. | ≤ 0.05 |
| Input Impedance | Ω | 350 ± 5 |
| Output Impedance | Ω | 350 ± 5 |
| Temp. Effect on Sensitivity | %F.S./10℃ | 0.1 |
| Temp. Effect on Zero | %F.S./10℃ | 0.1 |
| Insulation Resistance | MΩ (100VDC) | ≥ 5000 |
| Recommended Excitation | V | 5 ~ 15 |
| Max. Excitation | V | 20 |
| Compensated Temp. Range | ℃ | -10 ~ +60 |
| Operating Temp. Range | ℃ | -20 ~ +80 |
| Safe Overload | %F.S. | 120 |
| Ultimate Overload | %F.S. | 150 |
| Cable Size | mm | Φ3 × 3000 |
| Material | – | Aluminium Alloy |
| Cable Wiring Color | – | Red: EXC+, Black: EXC-, Green: Torque A+, Yellow: Speed B+, White: Torque A-, Blue: Speed B-, Brown: RS485 A+/RS232 Txd/CAN H+, Grey: RS485 B-/RS232 RxD/CAN L- |
