The ZMXW bending beam load cell is available in a wide range of capacities from 5kg through to 1000kg allowing for a multitude of applications. All stainless steel and hermetically sealed the compact size of the ZMWX makes it the ideal choice for multi-head weighing equipment and low capacity vessel and hopper weighing systems.
Nickel plated alloy steel
The ZMYL series of pressure sensors are cost-effective products designed for high volume, low cost industrial and civil pressure measurement field.
The ZMYS circular S type tension load cell offers a wide range of capacities, extending from 1kg to 5000kg. Constructed from alloy steel with an electroless nickel-plated surface, it’s a robust and reliable choice. We provide optional amplifer which converts analog sigal into 4-20mA, 0-5V or 0-10V.
Nickel plated alloy steel
The ZMZL series tension sensors offer the highest accuracy, reliability, and durability in the industry. Utilizing a combination of stainless steel construction, a built in mechanical hard stop, and individual sensor performance verification, the ZMZL series tension sensors are perfect for all high performance running web applications.
Nickel plated alloy steel
The ZMZS coulmn S type tension load cell offers a wide range of capacities, extending from 1KN to 200KN. Constructed from alloy steel with an electroless nickel-plated surface, it’s a robust and reliable choice. We provide optional amplifer which converts analog sigal into 4-20mA, 0-5V or 0-10V.
Nickel plated alloy steel
The display uses a 24 bit A / D converter, can be connected to various types of sensors and transmitters to achieve the pressure, flow, level, composition analysis and volume measurements, and other physical and mechanical parameters, display, alarm monitoring, data acquisition and recording.
Baud rate 19200
ZMDN is a high-precision rotarting torque sensor. The max rotating speed that the sensor can accept is 3000rpm. The output signal of ZMDN is from 1.0-1.5mv/v. Analog transmitter 4-20mA, 0-5V, 0-10V is optional.
Stainless steel body
The ZMMLB weighing module is designed for spoke type load cells up to 100t capacities. The load cell is with high accuracy and high stability pancake type. Stainless steel construction is optional.
Features:
Nickel plated alloy steel
The ZMNJ is a non-rotating type torque transducer that converts a torsional mechanical input into an electrical output signal. The ZMNJ can be used in both clockwise and counterclockwise direction ranging from 1Nm up to 200Nm. The sensor is used in static and non-rotating torsion measure applications.
Nickel plated alloy steel
Flange to square torque sensor ZMNJF is a non-rotating type torque transducer that converts a torsional mechanical input into an electrical output signal. ZMNJF can be used in both clockwise and counterclockwise direction ranging from 1Nm up to 500Nm. The measuring range and flange/square size can be customized to meet customer’s requirements.
Nickel plated alloy steel
The ZMNJF2 is a non-rotating type torque transducer that converts a torsional mechanical input into an electrical output signal. The ZMNJF2 can be used in both clockwise and counterclockwise direction ranging from 1000Nm up to 5000Nm. The sensor is used in static and non-rotating torsion measure applications.
Nickel plated alloy steel
The ZMX1 is a self-aligning complete with a zinc plated, steel mounting flange. Low profile in design it ensures precise load introduction in applications subject to thermal expansion or vibration. The ZMX1 is widely used in hopper and tank weighing systems, mixing vessel weighing systems.
Nickel plated alloy steel
The ZMX7 is bending beam load cell mounting kit. The load cell offers fast signalling times and optimal transparency in dosing and weighing processes.
Nickel plated alloy steel
The ZMZNJ is dual range shaft torque sensor. The torque sensor measures shaft-shaft type connection, measuring torsion by strain gages. There are both analog and digital output signals available for evaluation. The stainless steel construction is optional.
Nickel plated alloy steel
The ZMZX1 is column type compression mounting kit. The load cell offers fast signalling times and optimal transparency in dosing and weighing processes. With an output signal of 2.0 mV/V, load levels of up to 100 t, accuracy classes up to C3 and high-quality alloy steel, it has a wide range of potential applications.
Nickel plated alloy steel
