Product description:
DB903A is a double ended shear beam, both ends loaded, center supported via self-aligning ring groove structure, so that the force can be applied properly. This load cell is suitable for a wide range of truck scales, rail scales and process weighing equipment of tank, bin and hopper scale, etc. It is bolted at both ends.. Fully alloy steel construct, hermetically sealed, which ensure high seals performance of waterproof.
Main Features:
• Material: Alloy steel
• Rated Capacities: 10klb~250klb
• IP Rating: IP68
• Suitable for truck scale, heavy duty hopper scale and other electronic weighing devices.
• High precision by NTEP III L 10000, high reliability.
Category: Double shear beam
Product description:
DB916A is a double ended shear beam, both ends loaded, center supported via self-aligning column structure, so that the force can be applied properly. This load cell is suitable for a wide range of truck scales, rail scales and process weighing equipment of tank, bin and hopper scale, etc. It is bolted at both ends.. Fully alloy steel construct, hermetically sealed, which ensure high seals performance of waterproof.
Main Features:
• Material: Alloy steel
• Rated Capacities: 2.5klb~100klb
• IP Rating: IP68
• Suitable for truck scale, heavy duty hopper scale and other electronic weighing devices.
• High precision by NTEP III L 10000, high reliability.
Category: Double shear beam
Product description:
DB923A is a double ended shear beam, both ends loaded, center supported via self-aligning semicircular groove structure, so that the force can be applied properly. This load cell is suitable for a wide range of truck scales, giant vessel scales and rail scales. It is designed to use parallel link loading at both ends. Fully alloy steel construct, hermetically sealed, which ensure high seals performance of waterproof.
Main Features:
• Material: Alloy steel
• Rated Capacities: 50klb~125klb
• OIML NTEP HB44, CE and RoHS certified
• IP Rating: IP68
• Suitable for truck scale, heavy duty hopper scales and other electronic weighing devices.
• High precision by NTEP III L 10000, high reliability.
Category: Double shear beam
Product description:
DB940A is a double ended shear beam, both ends loaded, center supported via self-aligning semicircular arc convex structure, so that the force can be applied properly. This load cell is suitable for a wide range of truck scales, giant vessel scales and rail scales. It is designed to be lifted via a pair of parallel connected ring at both ends. Fully alloy steel construct, hermetically sealed, which ensure high seals performance of waterproof.
Main Features:
• Material: Alloy steel
• Rated Capacities: 25klb~100klb
• OIML NTEP HB44, CE and RoHS certified
• IP Rating: IP68
• Suitable for truck scale, heavy duty hopper scales and other electronic weighing devices.
• High precision by NTEP III L 10000, high reliability.
Category: Double shear beam
Product description:
DB958A is a double ended shear beam, both ends loaded, center supported via self-aligning saddle structure, so that the force can be applied properly. This load cell is suitable for a wide range of truck scales, giant vessel scales and rail scales. It is bolted at both ends. Fully alloy steel construct, hermetically sealed, which ensure high seals performance of waterproof.
Main Features:
• Material: Alloy steel
• Rated Capacities: 10klb~200klb
• OIML NTEP HB44, CE and RoHS certified
• IP Rating: IP68
• Suitable for truck scale, heavy duty hopper scales and other electronic weighing devices.
• High precision by NTEP III L 10000, high reliability.
Category: Double shear beam
- 220kg–4.4ton
- Ultrahigh accuracy
- Made of stainless steel
- Particularly good environmental resistance
- Hermetic seal
-
50kg–200kg
- Ultrahigh accuracy, Non Linearity: 0.0110%R.C.
- Particularly good environmental resistance
- High Capacity Beam Load Cell (Rating: 5TON, 10TON)
- Compact design of low overall height.
- Made of galvanized steel
- IP Rating: IP67
Features
Capacity: 15, 30, 75 kg
Material: Aluminum
Type: Single Point
Protection Rating: IP67
Capacity: 10, 20, 30, 50, 100, 200, 300, 500 kg
Material: Stainless steel
Type: Bending-Type
Protection Rating: IP68
Capacity: 110, 220, 550 kg; 1.1, 2.2, 3, 4.4 t
Material: Stainless steel
Type: Beam Digital
Protection Rating: IP68
Capacity: 250, 500 kg; 1, 2, 3, 5 t
Material: Alloy steel
Type: Shear Beam
Protection Rating: IP68
Capacity: 110, 220, 250, 500, 550 kg; 1, 1.1, 2, 2.2, 3, 4.4, 5 t
Material: Stainless steel
Type: Shear Beam
Protection Rating: IP68
Capacity: 7.5, 10 t
Material: Stainless steel
Type: Shear Beam
Protection Rating: IP68 / IP69K
Capacity: 10, 20, 30 kg
Material: Stainless steel
Type: Shear Beam
Protection Rating: IP68
