- Capacities: 0-10kg up to 0-500kg
- Output: 2mV/V
- Environmental Protection: IP68
- High Accuracy: <±0.02%/RC
- Optional Vessel Mounts
- Ideal for Accurate Batch Hopper Weighing Applications
- Hermetically Sealed & Immersion Protected for Food Hygiene Environments
- Optimum Accuracy Guaranteed with Vessel Mounts
- Optimise Signal Integrity and Reduce Noise – With our Integrated Signal Conditioning Options
- Capacities: 0-2te up to 0-1000te
- Output: 1.5mV/V
- Sealed to IP67 (IP68 submersible versions available)
- Stainless Steel Construction
- Optional Amplifier Output & Integral Connector
- Can be Supplied with Loading Cap & Mounting Base
- Long-Term Submersible Versions Available – Ideal for marine and offshore applications.
- Lower Height Versions Available – To fit within your specific application.
- Fast and Easy Installation – With our loading cap and mounting bases.
- Immersion protected to 1 metre – for up to 30 mins.
- Carry Handles Supplied for Units Over 200t
- Get it Fast – Shorter delivery times on lower capacities.
- Capacities: 0-500kg up to 0-5000kg
- Output: 2mV/V
- Environmental Protection: IP68
- High Accuracy: <±0.025%/RC
- Optional Mounting Accessories
- Optional ATEX (EEx ia IIC T6)
- Optimum Accuracy Guaranteed with Shock or Vessel Mounts
- Suitable for Wash-Down Applications
- Ideal for Food Hygiene Environments, Off-Shore & Marine Applications
- Optimise Signal Integrity and Reduce Noise – With our Integrated Signal Conditioning Options
- ATEX (EEx ia IIC T6) Hazardous Area Approvals Available
- Capacities: 0-10kg up to 0-200kg
- Output: 2mV/V
- Environmental Protection: IP67
- High Accuracy: <±0.03%/Rated Capacity
- ATEX Certificate: EEx ia IIC T4
- Designed for Low Range Measurement Applications – Ideal in Weighing Scales
- Suitable for Industrial Environments
- Ideal for retrofitting into existing designs
- Lightweight & Low Cost
- High Accuracy Guaranteed
- Customised Versions
- Immersion Protection up to 1m on Request
- Capacities: 0-250kg up to 0-2000kg
- Output: 2mV/V
- Environmental Protection: IP67
- High Accuracy: <±0.025%/RC
- Optional Mounting Accessories
- Optional ATEX (EEx ia IIC T6)
- Optimum Accuracy Guaranteed with Shock or Vessel Mounts
- Ideal for Harsh Industrial Environments – Immersion Protected to 1m to up to 30 mins
- Optimise Signal Integrity and Reduce Noise – With our Integrated Signal Conditioning Options
- Low Cost for Price Sensitive Applications
- ATEX (EEx ia IIC T6) Hazardous Area Approvals Available
- Capacities: 0-0.7kN up to 0-5kN
- Output: 2mV/V ±0.1%
- Hermetically Sealed
- Fully Submersible IP68 Rated to 2m/0.2bar
- Simple To Install
- High Accuracy: <±0.02%/FS
- Designed for Permanent Long-Term Submersion to 2m/0.2bar
- Ideal for Hydrostatic Testing and Off-Shore Applications
- Hermetically Sealed – Ideal for Harsh Industrial Environments
- Improved Accuracy – With our specially designed rod end bearings which reduce extraneous forces.
- Fast and Simple Installation – With standard or customised mounting bases and design fixtures.
- Capacities: 0-50kg up to 0-6,000kg
- Output: 2mV/V
- Environmental Protection: IP67
- Accuracy: <±0.05%/RC
- Simple To Install
- Guaranteed High Performance – With dual bending beam and shear web designs.
- IP67 Immersion Protection as Standard to 1m
- Fully Submersible Versions Available – Ideal for permanent marine and offshore applications.
- Improved Accuracy – Specially designed rod end bearings which reduce extraneous forces.
- Fast and Simple Installation – With standard or customised mounting bases and design fixtures.
Bellow beam load cell, anti-fatigue, anti-eccentric load, can withstand two working modes of tension and compression.
| Model | AB51C |
|---|---|
| Capacity | 00.1，0.2，0.3，0.5，1，2,3，5，7，10 (kN) |
| Creep | ±0.02%F.S/30min |
| Sensitivity | 2.0mv/v |
| Material | Alloy steel |
| Certificate | RoHS, CE |
AP61A parallel beam load cell also called single point load cell, has 3kg,6kg,10kg,20kg,50kg, 100kg weight range, suitable for 250×350mm platform scale.
| Model | AP61A |
|---|---|
| Capacity | 3kg,6kg,10kg,20kg,50kg,100kg |
| Max.platform size | 250×350mm |
| Accuracy | 0.02%F.S |
| Creep | 0.02%/30min |
| Input resistance | 405±10Ω |
| Output resistance | 350±3Ω |
| Material | High quality Aluminum alloy |
AP61AD Digital Parallel Beam Load Cell is a high-precision weighing sensor equipped with integrated signal processing and digital communication interfaces, including RS485 and RS232. This sensor is specially designed for applications requiring reliable data transmission, enhanced noise immunity, and simplified system integration.
| Model | AP61AD |
|---|---|
| Capacity | 0~50(kg) |
| Max.platform size | 250×350mm |
| Accuracy | C4, 0.0025% |
| Output signal | RS232,RS485,19200 Baud rate |
| Creep | 0.018%/30min |
| Material | High quality Aluminum alloy |
AP61A parallel beam load cell also called single point load cell, is suitable for 250*350mm platform scale.
| Model | AP61BN |
|---|---|
| Capacity | 20kg, 60kg, 100kg 150kg,200kg,300kg |
| Size | 130*38*22mm |
| Accuracy | ±0.02%F.S |
| Certificate | RoHS, CE |
| Creep | ±0.02%F.S/30min |
| Material | Aluminum alloy |
| Sensitivity | 2.0±10%mV/V |
AP61A parallel beam load cell also called single point load cell, is suitable for 250*350mm platform scale.
| Model | AP62A |
|---|---|
| Capacity | 25kg,40kg,60kg,100kg,200kg,350kg |
| Size | 150*40*35mm |
| Accuracy | ±0.02%F.S |
| Creep | ±0.02%F.S/30min |
| Material | Aluminum alloy |
| Sensitivity | 2.0±5%mV/V |
AP62B parallel beam load cell also called single point load cell, is suitable for 400*400mm platform scale.
| Model | AP62B |
|---|---|
| Capacity | 60kg,100kg,200kg,300kg,500kg,600kg,800kg,1000kg |
| Size | 174*60*64mm |
| Accuracy | ±0.02%F.S |
| Creep | ±0.02%F.S/30min |
| Material | Aluminum alloy |
| Sensitivity | 2.0±5%mV/V |
AP62C Single point load cell 60~500kg , is suitable for 400*400mm platform scale.
| Model | AP62C |
|---|---|
| Accuracy | ±0.02%F.S |
| Capacity | 60kg 100kg 200kg 350kg 500kg |
| Input resistance | 405±10Ω |
| Output resistance | 350±3Ω |
| Material | Aluminum alloy |
AP62H parallel beam load cell also called single point load cell, has 60kg, 100kg, 200kg 300kg weight range, suitable for 400*400mm platform scale.
| Model | AP62H |
|---|---|
| Capacity | 60~300kg |
| Max.platform size | 400×400mm |
| Accuracy | 0.02%F.S |
| Creep | 0.03%/30min |
| Input resistance | 405±10Ω |
| Output resistance | 350±3Ω |
| Material | High quality Aluminum alloy |
AP62HD Digital Parallel Beam Load Cell is a high-precision weighing sensor equipped with integrated signal processing and digital communication interfaces, including RS485 and RS232. This sensor is specially designed for applications requiring reliable data transmission, enhanced noise immunity, and simplified system integration.
| Model | AP62HD |
|---|---|
| Capacity | 60，100，200，350，500(kg) |
| Max.platform size | 400×400mm |
| Accuracy | C4 |
| Output signal | RS232,RS485,19200 Baud rate |
| Division Value | ≤50kg，1g 60～100kg，2g 150～200kg，5g 300～500kg，10g |
| Temp. effect on zero | 0.002%/10℃ |
| Material | High quality Aluminum alloy |
