Thanks to the efforts of our staff,Ningbo Santwell Import & Export Co., Ltd can launch our IP67 CZL s-type load cell Impact 5kg Load Cell Sensor 25kg S Beam Load Cell for Crane Scales AST02 50kg release meeting as scheduled. Our Force Sensors & Load Cells is supplied with a competitive price . Designed by professional designers, IP67 CZL s-type load cell Impact 5kg Load Cell Sensor 25kg S Beam Load Cell for Crane Scales AST02 50kg is attractive in its appearance. So, shake hands with us, expand your business, and increase your clientele.
| Model Number: | AST02 | Type: | Load Cell |
| Place of Origin: | Zhejiang, China | Brand Name: | SANTWELL |
| Usage: | crane scale, belt scale, hangling scale | Theory: | Resistance strain |
| Output: | 2.0000±0.002mv/v | Description: | S type load cell |
| Rated Load: | 5t | Sensitivity: | 2.0000±0.002mV/V |
| Total Error: | ±0.02%F.S | Creep(30minutes): | ±0.02%F.S |
| Recommended Excitation Voltage: | 5V~12V(AC or DC) | Maximum Excitation Voltage: | 15V(AC or DC) |
| Zero Balance: | ±1%F.S | Insulation Impedance: | ≥5000MΩ |
| Safe Overload: | 150%F.S | Ultimate Overload: | 200%F.S |
People with different backgrounds purchase Weighing Sensors Portable Tension Load Cell 200kg Weighting Pressure Sensor S Beam Load Cells With Cable AST03 no matter the budget because of the effectiveness of these product. It is designed to meet the industry criterion. In this technology-driven society, 2014 focus on improving R&D strength and keep developing new technologies so as to increase our competitiveness in the industry. We aim to become one of the leading enterprises in the market.
| Model Number: | AST03 | Type: | Load Cell |
| Brand Name: | China | Usage: | crane scale, belt scale, hangling scale |
| Theory: | Resistance strain | Output: | 2.0000±0.002mv/v |
| Description: | S type load cell | Rated Load: | 10t |
| Sensitivity: | 2.0000±0.002mV/V | Total Error: | ±0.02%F.S |
| Creep(30minutes): | ±0.02%F.S | Recommended Excitation Voltage: | 5V~12V(AC or DC) |
| Maximum Excitation Voltage: | 15V(AC or DC) | Zero Balance: | ±1%F.S |
| Insulation Impedance: | ≥5000MΩ | Safe Overload: | 150%F.S |
| Ultimate Overload: | 200%F.S |
We always create a perfect quality of product at prices that meet a customer’s budget. It is consistent with industry standards. We strictly stick to the concept of scientific design, which contributes to the unique appearance and easy-to-use performance of our Load cells, Subminiature force transducers, miniature load cells, Intelligent load cells. Also, we never use inferior raw materials and ensure they are all tested by our QC inspectors, thereby, guaranteeing Force Sensors & Load Cells quality. We believe that our product with so many advantages can bring benefits to all customers.
| Model Number: | AST04 | Type: | Load Cell |
| Place of Origin: | Zhejiang, China | Brand Name: | Santwell |
| Rated Load: | 0.5t,1t,2t,5t,10t,15t,20t | Sensitivity: | 2.0000±0.002mV/V |
| Total Error: | ±0.02%F.S | Creep(30minutes): | ±0.02%F.S |
| Recommended Excitation Voltage: | 5V~12V(AC or DC) | Maximum Excitation Voltage: | 15V(AC or DC) |
| Zero Balance: | ±1%F.S | Insulation Impedance: | ≥5000MΩ |
| Safe Overload: | 150%F.S | Ultimate Overload: | 200%F.S |
Ningbo Santwell Import & Export Co., Ltd has become a recognized leader in the Force Sensors & Load Cells industry with its high-quality product and excellent service. It better meets the market demands. Ningbo Santwell Import & Export Co., Ltd have long desired to become one of the most influential enterprises in the industry. At present, we are busy improving our capabilities in product manufacturing, and gathering talents especially technical talents to develop our own core technologies.
| Model Number: | AST05 | Place of Origin: | Zhejiang, China |
| Brand Name: | Santwell | Usage: | PRESSURE SENSOR |
| Theory: | Resistance Sensor | Output: | Analog SENSOR |
| Rated Load: | 0.5t,1t,2t,3t,5t,7.5t,10t,15t,20t | Sensitivity: | 2.0000±0.002mV/V |
| Total Error: | ±0.02%F.S | Creep(30minutes): | ±0.02%F.S |
| Recommended Excitation Voltage: | 5V~12V(AC or DC) | Maximum Excitation Voltage: | 15V(AC or DC) |
| Zero Balance: | ±1%F.S | Insulation Impedance: | ≥5000MΩ |
| Safe Overload: | 150%F.S | Ultimate Overload: | 200%F.S |
| Place of Origin: | Zhejiang, China | Brand Name: | Santwell |
| Model Number: | B08 | Power Supply: | -7mV ~ 12.8mV |
| Display Type: | 6-digit 20mm LED or 25mm LCD with backlight | Display: | 6-digit 20mm LED or 25mm LCD with backlight |
| Accuracy class: | OIML III | Input voltage: | -7mV ~ 12.8mV |
| Resolving: | display15000, internal code 1000000 | Excitation voltage: | DC3.3V |
| Functions: | accumulate, hold, animal weighing, check, sort |
| Warranty: | 1 year | Customized support: | OEM |
| Place of Origin: | Zhejiang, China | Brand Name: | Yaohua |
| Model Number: | B19P | Power Supply: | 220V |
| Display Type: | 6 bits LCD , 6 state indicating signals | Accuracy: | Gradelll,n=3000 |
| Sample Rate: | 10 times/second | Load cell sensitivity: | 1.5~3mV/V |
| Scale interval: | 1/2/5/10/20/50 for option | Scoreboard interface (optional): | In serial output mode:current loop signal, transmission distance≤50m |
| Communication interface (optional): | RS232C ; Baud rate 1200/2400/4800/9600 optional | Power supply: | Battery DC6V/4AH |
| Operating temperature/humidity: | 0-40℃;≤90%RH | Transporting temperature: | -20~50℃ |
As one of the most popular products, B19S Plastic Housing Digital Cheap Waterproof Weighing Indicator wins increasing popularity. LP7516 Plastic Housing Digital Cheap Waterproof Weighing Indicator starting from the user experience and using strong research and development capabilities, it can effectively solving the pain points of the industry. Ningbo Santwell Import & Export Co., Ltd will keep pace with the tide and focus on improving technologies, thereby creating and manufacturing products that better suit the needs of customers. We aim to lead the market trends one day.
| Customized support: | ODM | Place of Origin: | Zhejiang, China |
| Brand Name: | Santwell | Model Number: | B19S |
| Power Supply: | -7mV ~ 12.8mV | Display Type: | 6-digit 20mm LED or 25mm LCD with backlight |
| Display: | 6-digit 20mm LED or 25mm LCD with backlight | Accuracy class: | OIML III |
| Input voltage: | -7mV ~ 12.8mV | Resolving: | display15000, internal code 1000000 |
| Excitation voltage: | DC3.3V | Functions: | accumulate, hold, animal weighing, check, sort |
| Customized support:: | OEM | Load cell interface: | 4-wire, 1~4 350Ω analog load cell(s) |
| Power supply: | AC110/220V 50/60Hz or built-in 4V/4Ah lead acid battery | Work environment: | -10℃ ~ +40℃, ≤85%RH |
| Place of Origin: | Zhejiang, China | Brand Name: | Santwell |
| Model Number: | B08 | Power Supply: | -7mV ~ 12.8mV |
| Display Type: | 6-digit 20mm LED or 25mm LCD with backlight | Display: | 6-digit 20mm LED or 25mm LCD with backlight |
| Accuracy class: | OIML III | Input voltage: | -7mV ~ 12.8mV |
| Resolving: | display15000, internal code 1000000 | Excitation voltage: | DC3.3V |
| Functions: | accumulate, hold, animal weighing, check, sort |
Ningbo Santwell Import & Export Co., Ltd through years of painstaking research, relying on mature R&D technology and precise market positioning, we have created BBM IP68 Stainless Steel 24V Bending Beam Load Cell Silo Load Cell Weight Sensor. Since launched, BBM IP68 Stainless Steel 24V Bending Beam Load Cell Silo Load Cell Weight Sensor has been receiving mounting acclaim from customers. Ningbo Santwell Import & Export Co., Ltd always adhere to the principle of ‘creating values for customers and bringing benefits to stakeholders’. In the process of development, we highly focus on the quality and ensure no flawless product delivered to customers.
| Model Number: | BBM | Type: | Load Cell |
| Place of Origin: | Zhejiang, China | Brand Name: | santwell |
| Usage: | hopper scale, belt scale, blending system | Theory: | Resistance strain |
| Output: | 2.0000±0.002mv/v | Description: | Bending beam load cell |
| Rated Load: | 5-500kg | Sensitivity: | 2.0000±0.002mV/V |
| Total Error: | ±0.1%F.S | Creep(30minutes): | ±0.01%F.S |
| Recommended Excitation Voltage: | 5V~18V(AC or DC) | Maximum Exxcitation Voltage: | 24V(AC or DC) |
| Zero Balance: | ±1%F.S | Insulation Impedance: | ≥5000MΩ |
| Safe Overload: | 150%F.S | Ultimate Overload: | 200%F.S |
| Model Number: | BBM-(M) | Place of Origin: | Zhejiang, China |
| Brand Name: | SANTWELL | Usage: | PRESSURE SENSOR |
| Theory: | Resistance Sensor | Output: | Analog SENSOR |
| Rated Load: | 10-500KG | Sensitivity: | 2.0000±0.002mV/V |
| Total Error: | ±0.02%F.S | Creep(30minutes): | ±0.02%F.S |
| Recommended Excitation Voltage: | 5V~18V(AC or DC) | Maximum Excitation Voltage: | 24V(AC or DC) |
| Zero Balance: | ±1%F.S | Insulation Impedance: | ≥5000MΩ |
| Safe Overload: | 150%F.S | Utimate Overload: | 200%F.S |
| Model Number: | BHA | Place of Origin: | Zhejiang, China |
| Brand Name: | santwell | Usage: | PRESSURE SENSOR |
| Theory: | Resistance Sensor | Output: | Analog SENSOR |
| Rated Load: | 5t,6t,7.5t,8t,10t,12t,18t,20t | Sensitivity: | 2.0000±0.002mV/V |
| Total Error: | ±0.05%F.S | Creep(30minutes): | ±0.02%F.S |
| Recommended Excitation Voltage: | 5V~12V(AC or DC) | Maximum Excitation Voltage: | 15V(AC or DC) |
| Zero Balance: | ±1%F.S | Insulation Impedance: | ≥5000MΩ |
| Safe Overload: | 150%F.S | Ulitimate Overload: | 200%F.S |
Model No.: BHB
Brand: santwell
place of origin: China
Pattern: Bridge Type
Transform Type: Resistance Strain
Out-Wire: 4-Wire
Output Signal Type: Analog Type
Material: Metal
IP Rating: Ip67
Certification: Ce
Customized: Non-Customized
Rated Load: 10t
Supply Ability & Additional Information
Packaging: pcs/carton
Productivity: 1000pcs/month
Transportation: Ocean,Land,Air
Place of Origin: Zhengjiang,China
Supply Ability: 1000pcs/month
| Model Number: | BHC | Place of Origin: | Zhejiang, China |
| Brand Name: | Santwell | Usage: | PRESSURE SENSOR |
| Theory: | Resistance Sensor | Output: | Analog SENSOR |
| Rated Load: | 3-50t | Sensitivity: | 2.0000±0.002mV/V |
| Total Error: | ±0.02%F.S | Creep(30minutes): | ±0.02%F.S |
| Recommended Excitation Voltage: | 5V~12V(AC or DC) | Maximum Excitation Voltage: | 15V(AC or DC) |
| Zero Balance: | ±1%F.S | Insulation Impedance: | ≥5000MΩ |
| Safe Overload: | 150%F.S | Ultimate Overload: | 200%F.S |
| Model Number: | BHF | Type: | Load Cell |
| Place of Origin: | Zhejiang, China | Brand Name: | santwell |
| Usage: | crane scale | Theory: | resistant strain |
| Output: | 2.0mv/V | Description: | load cell |
| Rated Load: | 5t,6t,7.5t,8t,10t,12t,18t,20t | Sensitivity: | 2.0000±0.002mV/V |
| Total Error: | ±0.05%F.S | Creep(30minutes): | ±0.02%F.S |
| Recommended Excitation Voltage: | 5V~12V(AC or DC) | Maximum Excitation Voltage: | 15V(AC or DC) |
| Zero Balance: | ±1%F.S | Insulation Impedance: | ≥5000MΩ |
| Safe Overload: | 150%F.S | Ulitimate Overload: | 200%F.S |
| Model Number: | BHG | Place of Origin: | Zhejiang, China |
| Brand Name: | Santwell | Usage: | PRESSURE SENSOR |
| Theory: | Resistance Sensor | Output: | Analog SENSOR |
| Rated Load: | 3t,5t,10t | Sensitivity: | 2.0000±0.002mV/V |
| Total Error: | ±0.3%F.S | Creep(30minutes): | ±0.02%F.S |
| Recommended Excitation Voltage: | 5V~12V(AC or DC) | Maximum Excitation Voltage: | 15V(AC or DC) |
| Zero Balance: | ±1%F.S | Insulation Impedance: | ≥5000MΩ |
| Safe Overload: | 150%F.S | Ultimate Overload: | 200%F.S |
| Warranty: | 1 years | Customized support: | OEM, ODM |
| Place of Origin: | Zhejiang, China | Brand Name: | Santwell |
| Model Number: | C101 | Power Supply: | -3mV ~ 30mV |
| Display Type: | 6-digit 10mm LED display | Accuracy class: | OIML III |
| Input voltage: | -3mV ~ 30mV | Resolving: | display30000, internal code 2000000 |
| Excitation voltage: | DC5V | Power supply: | AC220V 50/60Hz DC24V |
