Small size half bridge load cell 50kg, 30*25*2.5mm
| Model | AM24C |
|---|---|
| Accuracy | ±0.1%F.S |
| Capacity | 50kg |
| Creep | ±0.1%F.S/3min |
| Material | manganese steel |
| Size | 30*25*2.5mm |
The AM33B load cell weight range is from 100g to 2000g, The load material is Aluminum alloy. Safe overload is 120%.
| Certificate | RoHS, CE |
|---|---|
| Accuracy | ±0.05%F.S |
| Capacity | 100g 200g 300g 500g 750g, 1kg, 2kg |
| Creep | ±0.05%F.S/3min |
| Material | Aluminum alloy |
| Model | AM33B |
| Sensitivity | 0.7±0.15mV/V |
| Size | 47*12*6 |
AM34A micro load cell capacity is 2kg. Accuracy is 0.1 %F·S. Size is 30×8.5×6 (4.8)mm, standard wire length is Φ0.65x 100mm.
| Accuracy | ±0.1%F.S |
|---|---|
| Capacity | 2kg |
| Certificate | RoHS, CE |
| Creep | ±0.1%F·S/ 2min |
| Material | Aluminum alloy |
| Model | AM34A |
| Sensitivity | 0.7 ±0.2 mv/v |
| Size | 30×8.5×6 (4.8)mm |
AM34B micro load cell weight range is 300g, 500g, 750g, 1kg, 2kg, 3kg,5kg；the accuracy is 0.05 % F.S；size is 45×9.3×6 mm；the cable is Φ0.8x200mm.
| Accuracy | 0.05%F.S |
|---|---|
| Capacity | 300g, 500g, 750g, 1kg, 2kg, 3kg,5kg |
| Certificate | RoHS, CE |
| Creep | 0.1%F·S/3min |
| Material | Aluminum alloy |
| Model | AM34B |
| Sensitivity | 300g: 0.7±0.15MV/V, 500g-750g: 0.8±0.15 MV/V, 1kg-5kg: 1.0±0.15 MV/V |
| Size | 45×9.3×6 mm |
AM34c micro load cell weight range is from 1kg to 50 kg；the accuracy is 0.05 %F·S；The size is 58×12.7×12.7 mm；the cable is Φ0.8x100mm.
| Accuracy | 0.05 %F·S |
|---|---|
| Capacity | 1kg-50 kg |
| Certificate | RoHS, CE |
| Creep | ±0.05 %F·S/3min |
| Material | Aluminum alloy |
| Model | AM34C |
| Sensitivity | 1.0 ± 0.15 mv/V |
| Size | 58×12.7×12.7 mm |
AM34D micro load cell have 10kg,20kg,30kg,40kg, 50kg, the accuracy is 0.3% F.S, small size 31.8*7.9*H mm, and the cable is Φ0.8×110mm.
| Accuracy | 0.3% F.S |
|---|---|
| Capacity | 10kg,20kg,30kg,40kg, 50kg |
| Certificate | RoHS, CE |
| Creep | 0.1 % F.S./3min |
| Material | manganese steel |
| Model | AM34D |
| Sensitivity | Table±0.2 mV/V |
| Size | 31.8*7.9*H mm |
AM34E micro load cell weight range is 3kg；the accuracy is 0.3%F.S；The size is 30 x 14 x 1 mm；the cable is 32AWG *120cm.
| Accuracy | 0.3%F.S |
|---|---|
| Capacity | 3kg |
| Certificate | RoHS, CE |
| Creep | 0.2% F.S/3min |
| Material | manganese steel |
| Model | AM34E |
| Sensitivity | 0.3±0.15mV/V |
| Size | 30x14x1 mm |
AM34F Micro load cell is special size, Size: 34 x 26 x 0.6 mm. weight range is 100g and the accuracy is 0.3%F.S.
| Accuracy | ±0.2%F.S |
|---|---|
| Capacity | 100g |
| Certificate | RoHS, CE |
| Creep | ±0.2%F.S/3min |
| Material | manganese steel |
| Model | AM34F |
| Sensitivity | 0.8±0.2mV/V |
| Size | 34x26x0.6mm |
Half bridge micro load cell 5kg for mini scales, uses four pcs together
| Model | AM23B |
|---|---|
| Size | 26*26*1mm |
| Capacity | 3kg, 5kg |
| Accuracy | ±0.1%F.S |
| Creep | ±0.1%F.S/3min |
| Material | manganese steel |
High precision ultra-thin micro load cell 10kg, 50kg, customized the wire length, connectors and load cell size.
| Accuracy | ±0.05%F.S |
|---|---|
| Size | 34*34*2mm |
| Capacity | 10kg, 30kg,50kg |
| Model | AM21A |
| Creep | 0.3%F.S/3min |
| Material | manganese steel |
High precision ultra-thin micro load cell 10kg, 50kg, customized the wire length, connectors and load cell size.
| Model | AM21B |
|---|---|
| Size | 34*34*2mm |
| Capacity | 10kg, 30kg,50kg |
| Creep | ±0.2%F.S/3min |
| Material | manganese steel |
Flat micro load cell with a center point force, OEM and ODM
| Accuracy | ±0.05%F.S |
|---|---|
| Capacity | 10kg, 30kg, 50kg, 75kg |
| Creep | 0.05%3min |
| Material | manganese steel |
| Size | 34*34*2.5mm |
Flat micro load cell with a center point force, OEM and ODM
| Model | AM21D |
|---|---|
| Size | 34*34*2.5mm |
| Capacity | 10kg, 30kg, 50kg, 75kg |
| Accuracy | ±0.05%F.S |
| Creep | 0.05%3min |
| Material | manganese steel |
Small weight range half bridge micro load cells 3kg, 5kg, 4 pcs in a set.
| Model | AM23A |
|---|---|
| Size | 26*26*1mm |
| Capacity | 3kg, 5kg |
| Accuracy | ±0.05%F.S |
| Creep | ±0.05%F.S/3min |
| Material | manganese steel |
Flat micro load cell with a center point force, OEM and ODM
| Accuracy | ±0.05%F.S |
|---|---|
| Capacity | 10kg, 30kg, 50kg, 75kg |
| Creep | 0.05%3min |
| Material | manganese steel |
| Size | 34*34*2.5mm |
Good precision Small bar micro load cell, can match HX711 circuit board or A/D module
| Model | AM31A |
|---|---|
| Size | 80*12.7*12.7mm |
| Capacity | 1kg, 5kg, 10kg, 10kg, 25kg |
| Accuracy | ±0.05%F.S |
| Creep | ±0.05% |
| Material | Aluminum alloy |
| Sensitivity | 1.0±0.15mv/v |
