AP61AD Digital Parallel Beam Load Cell is a high-precision weighing sensor equipped with integrated signal processing and digital communication interfaces, including RS485 and RS232. This sensor is specially designed for applications requiring reliable data transmission, enhanced noise immunity, and simplified system integration.
| Model | AP61AD |
|---|---|
| Capacity | 0~50(kg) |
| Max.platform size | 250×350mm |
| Accuracy | C4, 0.0025% |
| Output signal | RS232,RS485,19200 Baud rate |
| Creep | 0.018%/30min |
| Material | High quality Aluminum alloy |
AP61A parallel beam load cell also called single point load cell, is suitable for 250*350mm platform scale.
| Model | AP61BN |
|---|---|
| Capacity | 20kg, 60kg, 100kg 150kg,200kg,300kg |
| Size | 130*38*22mm |
| Accuracy | ±0.02%F.S |
| Certificate | RoHS, CE |
| Creep | ±0.02%F.S/30min |
| Material | Aluminum alloy |
| Sensitivity | 2.0±10%mV/V |
AP61A parallel beam load cell also called single point load cell, is suitable for 250*350mm platform scale.
| Model | AP62A |
|---|---|
| Capacity | 25kg,40kg,60kg,100kg,200kg,350kg |
| Size | 150*40*35mm |
| Accuracy | ±0.02%F.S |
| Creep | ±0.02%F.S/30min |
| Material | Aluminum alloy |
| Sensitivity | 2.0±5%mV/V |
AP62B parallel beam load cell also called single point load cell, is suitable for 400*400mm platform scale.
| Model | AP62B |
|---|---|
| Capacity | 60kg,100kg,200kg,300kg,500kg,600kg,800kg,1000kg |
| Size | 174*60*64mm |
| Accuracy | ±0.02%F.S |
| Creep | ±0.02%F.S/30min |
| Material | Aluminum alloy |
| Sensitivity | 2.0±5%mV/V |
AP62C Single point load cell 60~500kg , is suitable for 400*400mm platform scale.
| Model | AP62C |
|---|---|
| Accuracy | ±0.02%F.S |
| Capacity | 60kg 100kg 200kg 350kg 500kg |
| Input resistance | 405±10Ω |
| Output resistance | 350±3Ω |
| Material | Aluminum alloy |
AP62H parallel beam load cell also called single point load cell, has 60kg, 100kg, 200kg 300kg weight range, suitable for 400*400mm platform scale.
| Model | AP62H |
|---|---|
| Capacity | 60~300kg |
| Max.platform size | 400×400mm |
| Accuracy | 0.02%F.S |
| Creep | 0.03%/30min |
| Input resistance | 405±10Ω |
| Output resistance | 350±3Ω |
| Material | High quality Aluminum alloy |
AP62HD Digital Parallel Beam Load Cell is a high-precision weighing sensor equipped with integrated signal processing and digital communication interfaces, including RS485 and RS232. This sensor is specially designed for applications requiring reliable data transmission, enhanced noise immunity, and simplified system integration.
| Model | AP62HD |
|---|---|
| Capacity | 60，100，200，350，500(kg) |
| Max.platform size | 400×400mm |
| Accuracy | C4 |
| Output signal | RS232,RS485,19200 Baud rate |
| Division Value | ≤50kg，1g 60～100kg，2g 150～200kg，5g 300～500kg，10g |
| Temp. effect on zero | 0.002%/10℃ |
| Material | High quality Aluminum alloy |
AP61A parallel beam load cell also called single point load cell, is suitable for 250*350mm platform scale.
| Model | AP62N |
|---|---|
| Capacity | 60,100,200,350,500kg |
| Size | 150*40*35mm |
| Accuracy | ±0.02%F.S |
| Creep | ±0.02%F.S/30min |
| Material | Aluminum alloy |
| Sensitivity | 2.0±5%mV/V |
AP61A parallel beam load cell also called single point load cell, is suitable for 250*350mm platform scale.
| Model | AP63A |
|---|---|
| Capacity | 0.3,0.5,1.5,3,6kg |
| Size | 70*12*22mm |
| Accuracy | ±0.02%F.S |
| Creep | ±0.03%F.S/30min |
| Material | Aluminum alloy |
| Sensitivity | 1.0±10%mV/V |
AP63F Single point load cell 4~30kg，Recommend max platform: 200*200mm. Suitable for dynamic measurement and vibration environments.
| Accuracy | ±0.01%F.S |
|---|---|
| Size | 80*50*20mm |
| Creep | ±0.02%F.S/30min |
| Material | Aluminum alloy |
| Capacity | 4,6,10,20,30kg |
| Certificate | RoHS, CE |
| Model | AP65T |
| Sensitivity | 2.0±5%mV/V |
Max. platform size :250*350mm
| Accuracy | ±0.02%F.S |
|---|---|
| Certificate | RoHS, CE |
| Creep | ±0.02%F.S/30min |
| Capacity | 3,6,10,15,20,30,40kg |
| Material | Aluminum alloy |
| Model | AP65A |
| Size | 75*24*22mm |
Max. platform size :250*350mm
| Accuracy | ±0.02%F.S |
|---|---|
| Capacity | 20,40,60,100,200kg |
| Certificate | RoHS, CE |
| Material | Aluminum alloy |
| Model | AP65B |
| Sensitivity | 2.0±10%mV/V |
| Size | 75*30*22mm |
| Creep | ±0.02%F.S/30min |
Max.platform size :250*350mm
| Accuracy | ±0.02%F.S |
|---|---|
| Capacity | 20,30,40,50,100kg |
| Creep | ±0.02%F.S/30min |
| Material | Aluminum alloy |
| Sensitivity | 2.0±10%mV/V |
| Model | AP65C |
| Size | 125*45*29mm |
Max. platform size :250*350mm
| Capacity | 20,30,40,50,100kg |
|---|---|
| Creep | ±0.02%F.S/30min |
| Certificate | RoHS, CE |
| Material | Aluminum alloy |
| Sensitivity | 2.0±10%mV/V |
| Model | AP65D |
| Size | 130*22*15mm |
Max.platform size :150*150mm
| Accuracy | ±0.02%F.S |
|---|---|
| Certificate | RoHS, CE |
| Material | Aluminum alloy |
| Capacity | 1.5,3,6kg |
| Creep | ±0.03 %F·S/30min |
| Model | AP65E |
| Sensitivity | 1.0±10%mV/V |
| Size | 59*22*12mm |
Max.platform size :150*150mm
| Accuracy | ±0.02%F.S |
|---|---|
| Certificate | RoHS, CE |
| Capacity | 1.5,2,3,6kg |
| Creep | ±0.03 %F·S/30min |
| Material | Aluminum alloy |
| Model | AP65F |
| Sensitivity | 2.0±10%mV/V |
| Size | 80*22*12mm |
