| Model Number: | LFN | Type: | Load Cell |
| Place of Origin: | Zhejiang, China | Brand Name: | Santwell |
| Usage: | / | Theory: | / |
| Output: | / | Description: | shear beam load cell |
| Rated Load: | 0.5/1/2/3/5/10/20/30/40/50/60 T | Sensitivity: | 2.0000±0.002mv/v |
| Total Error: | ±0.02%F.S | Creep(30 minutes): | ±0.02%F.S |
| Recommended Excitation Voltage: | 5V-18V(AC or DC) | Maximum Excitation Voltage: | 24V(AC or DC) |
| Zero Balance: | ±1%F.S | Insulation Impedance: | ≥5000MΩ |
| Safe Overload: | ±150%F.S | UItimate Overload: | ±200%F.S |
After a long period of exploration,Ningbo Santwell Import & Export Co., Ltd has launched High Technology Industrial Weighing Alloy Steel prices of load cell spoke load cell 30 Ton LFR. We pride ourselves on our personalized and efficient service. In order to be able to successfully meet the challenges,Ningbo Santwell Import & Export Co., Ltd will continue to forge ahead on the road of technological innovation. In addition, it will also work hard to analyze the changing needs of the market and create better products for customers according to their needs.
| Model Number: | LFR | Place of Origin: | Zhejiang, China |
| Brand Name: | Santwell | Usage: | PRESSURE SENSOR |
| Theory: | Resistance Sensor | Output: | Analog SENSOR |
| Description: | spoke style load cell | Rated Load: | 0.5/1/2/3/5/10/30/40/50/60 |
| Sensitivity: | 2.0000±0.002mv/v | Total Error: | ±0.02%F.S |
| Creep(30 minutes): | ±0.02%F.S | Recommended Excitation Voltage: | 5V-18V(AC or DC) |
| Maximum Excitation Voltage: | 24V(AC or DC) | Zero Balance: | ±1%F.S |
| Insulation Impedance: | ≥5000MΩ | Safe Overload: | ±150%F.S |
| UItimate Overload: | ±200%F.S | Application: | Car weighter orbit weighter batching weighing |
| Model Number: | LFR-(M) | Type: | / |
| Place of Origin: | Zhejiang, China | Brand Name: | Santwell |
| Description: | shear beam load cell | Rated Load: | 0.5/1/2/3/5/10/20/30/40/50/60 T |
| Sensitivity: | 2.0000±0.002mv/v | Total Error: | ±0.02%F.S |
| Creep(30 minutes): | ±0.02%F.S | Recommended Excitation Voltage: | 5V-18V(AC or DC) |
| Maximum Excitation Voltage: | 24V(AC or DC) | Zero Balance: | ±1%F.S |
| Insulation Impedance: | ≥5000MΩ | Safe Overload: | ±150%F.S |
| UItimate Overload: | ±200%F.S |
Ningbo Santwell Import & Export Co., Ltd is capable of providing a quality range of LFT Batching Weighing 500 Kg 10 T 30 T 60 T Small Compression Spoke Type Load Cell Manufacturer. The team uses the most advanced production equipment and independent research and development technology to minimize LFT Batching Weighing 500 Kg 10 T 30 T 60 T Small Compression Spoke Type Load Cell Manufacturer development cycle and ensure the high quality and strong reliability of the product. In the future, Ningbo Santwell Import & Export Co., Ltd will focus on technological innovation, continuously improve service quality and develop better products, and is committed to providing customers with products and services that exceed expectations.
| Model Number: | LFT | Type: | Load Cell |
| Place of Origin: | Zhejiang, China | Brand Name: | Santwell |
| Description: | shear beam load cell | Rated Load: | 0.5/1/2/3/5/10/20/30/40/50/60 T |
| Sensitivity: | 2.0000±0.002mv/v | Total Error: | ±0.02%F.S |
| Creep(30 minutes): | ±0.02%F.S | Recommended Excitation Voltage: | 5V-18V(AC or DC) |
| Maximum Excitation Voltage: | 24V(AC or DC) | Zero Balance: | ±1%F.S |
| Insulation Impedance: | ≥5000MΩ | Safe Overload: | ±150%F.S |
| UItimate Overload: | ±200%F.S |
| Model Number: | LFW | Type: | Load Cell |
| Place of Origin: | Zhejiang, China | Brand Name: | Santwell |
| Description: | shear beam load cell | Rated Load: | 0.5/1/2/3/5/10/20/30/40/50/60 T |
| Sensitivity: | 2.0000±0.002mv/v | Total Error: | ±0.02%F.S |
| Creep(30 minutes): | ±0.02%F.S | Recommended Excitation Voltage: | 5V-18V(AC or DC) |
| Maximum Excitation Voltage: | 24V(AC or DC) | Zero Balance: | ±1%F.S |
| Insulation Impedance: | ≥5000MΩ | Safe Overload: | ±150%F.S |
| Usage: | PRESSURE SENSOR |
| Modle: | LP-B | Condition: | New |
| After Warranty Service: | Online support | Brand： | Santwell |
| Type: | Load Cell | Place of Origin: | China |
| Showroom Location: | None | Condition: | New |
| Key Selling Points: | High Productivity | Marketing Type: | Ordinary Product |
| Modle: | LP-C | After Warranty Service: | Online support |
| Customized support: | OEM | Place of Origin: | Zhejiang, China |
| Brand Name: | Santwell | Model Number: | LP7510 |
| Power Supply: | -5mV ~ 20mV | Display Type: | 6-digit 20mm LED or 25mm LCD with backlight |
| Display: | 6-digit 20mm LED or 25mm LCD with backlight | Accuracy class: | OIML III |
| Input voltage: | -5mV ~ 20mV | Resolving: | display50000, internal code 2000000 |
| Excitation voltage: | DC5V | Power supply: | AC110/220V 50/60Hz DC9V or built-in 6V/4Ah lead acid battery |
| Customized support: | OEM | Place of Origin: | Zhejiang, China |
| Brand Name: | Santwell | Model Number: | LP7510 |
| Power Supply: | -5mV ~ 20mV | Display Type: | 6-digit 20mm LED or 25mm LCD with backlight |
| Display: | LED or LCD with backlight | Accuracy class: | OIML III |
| Input voltage: | -5mV ~ 20mV | Excitation voltage: | DC5V |
| Power supply: | AC110/220V 50/60Hz DC9V or built-in 6V/4Ah lead acid battery | Material: | Carbon steel / Stainless Steel / Stainless Steel Waterproof |
| Customized support: | OEM | Place of Origin: | Zhejiang, China |
| Brand Name: | Santwell | Model Number: | LP7512 |
| Power Supply: | -10mV ~ 19.5mV | Display Type: | 6-digit 20mm LED or 25mm LCD with backlight |
| Display: | 6-digit 20mm LED or 25mm LCD with backlight | Accuracy class: | OIML III |
| Input voltage: | -10mV ~ 19.5mV | Resolving: | display50000, internal code 2000000 |
| Excitation voltage: | DC5V | Power supply: | AC110/240V 50/60Hz DC9V or built-in 6V/4Ah lead acid battery |
| Place of Origin: | Zhejiang, China | Brand Name: | Santwell |
| Model Number: | LP7512 | Power Supply: | -10mV ~ 19.5mV |
| Display Type: | 6-digit 20mm LED or 25mm LCD with backlight | Display: | 6-digit 20mm LED or 25mm LCD with backlight |
| Accuracy class: | OIML III | Input voltage: | -10mV ~ 19.5mV |
| Resolving: | display50000, internal code 2000000 | Excitation voltage: | DC5V |
| Power supply: | AC110/240V 50/60Hz DC9V or built-in 6V/4Ah lead acid battery |
| Place of Origin: | Zhejiang, China | Brand Name: | Santwell |
| Model Number: | LP7512 | Power Supply: | -10mV ~ 19.5mV |
| Display Type: | 6-digit 20mm LED or 25mm LCD with backlight | Display: | 6-digit 20mm LED or 25mm LCD with backlight |
| Accuracy class: | OIML III | Input voltage: | -10mV ~ 19.5mV |
| Resolving: | display50000, internal code 2000000 | Excitation voltage: | DC5V |
| Power supply: | AC110/240V 50/60Hz DC9V or built-in 6V/4Ah lead acid battery |
| Place of Origin: | Zhejiang, China | Brand Name: | Santwell |
| Model Number: | LP7515 | Power Supply: | -3mV ~ 12mV |
| Display Type: | 6-digit 20mm LED with backlight | Accuracy class: | OIML III |
| Resolving: | display50000, internal code 2000000 | Excitation voltage: | DC3.3 V |
| Power supply: | 3 AA-size batteries,or DC6V |
| Customized support: | OEM, ODM | Place of Origin: | Zhejiang, China |
| Brand Name: | Santwell | Model Number: | LP7516 |
| Power Supply: | -7mV ~ 12.8mV | Display Type: | 6-digit 20mm LED or 25mm LCD with backlight |
| Display: | 6-digit 20mm LED or 25mm LCD with backlight | Accuracy class: | OIML III |
| Input voltage: | -7mV ~ 12.8mV | Resolving: | display15000, internal code 1000000 |
| Excitation voltage: | DC3.3V | Functions: | accumulate, hold, animal weighing, check, sort |
| Customized support: | OEM | Place of Origin: | Zhejiang, China |
| Brand Name: | Santwell | Model Number: | LP7553 |
| Power Supply: | -6mV ~ 19.5mV | Display Type: | 6-digit 50mm LED or LCD with backlight |
| Accuracy class: | OIML III | Resolving: | display50000, internal code 2000000 |
| Excitation voltage: | DC3.3 V | Power supply: | AC110/220v 50/60Hz |
| Place of Origin: | Zhejiang, China | Brand Name: | Santwell |
| Model Number: | LP7580 | Power Supply: | -3mV ~ 20mV |
| Display Type: | 6-wire system | Accuracy class: | OIML III |
| Input voltage: | -3mV ~ 20mV | Resolving: | display30000, internal code 2000000 |
| Excitation voltage: | DC5V | Power supply: | AC110/220V 50/60Hz ,or built-in 6V/4Ah lead acid battery |
